HYPACK MAX & HYSWEEP...

Product Description

Equipment rental to supply a license of HYPACK & HYSWEEP acquisition and processing software. Comes with USB hard lock key for activation and software may be downloaded from manufacturer’s website.

HYPACK® MAX: Our standard package. It has everything you need to design your survey, collect and process your single beam data, and generate final products such as contours, plotting sheets, output for CAD, fly-through views, cross sections, and volumes calculations. The side scan sonar, subbottom, ADCP, and magnetometer collection and processing modules are standard features of HYPACK® MAX. You’ll need to add a HYSWEEP® license to include the modules for multibeam data collection and processing.

Design: HYPACK® contains powerful tools that let you quickly design your survey:

Set your geodetic parameters

Import background charts: DXF, DGN, S-57, TIF, MrSid, ARCS

Configure your survey equipment:

Equipment type

Connection information

Offset information

Create your planned lines:

Manual entry

Parallel & Perpendicular patterns

CHANNEL DESIGN automatically creates planned lines and cross section profiles for channels and turning basins.

ADVANCED CHANNEL DESIGN creates complex 3D surfaces for precise dredging and volume computations.

Editing: HYPACK® provides graphical editing and sounding selection routines that allow you to quickly prepare your survey data for plotting, export to CAD or several other final products. The SINGLE BEAM EDITOR of HYPACK® provides for:

Graphical review and editing of tracklines and depth profiles

Display of acoustic profile for network capable soundings

Display of design templates and previous survey profiles

Water level (tides) adjustments

Real time telemetry gauges

Manually entered tides

RTK Tides

Tide Adjustments between stations

Sound Velocity corrections

Sounding Reduction: There are several options for sounding reduction, depending on your final product:

SORT selects the shoalest soundings and prevents overwrites.

CROSS SORT selects random soundings and packs them in tight.

SOUNDING SELECTION selects min/max soundings and fills in between.

MAPPER is a binning routine that can select minimum, maximum, average, or sounding closest to cell center to represent each cell.
